Le Hussard diagrams - Looking for

[BoteEnjoyer]

Hello everyone, I am also currently working on the Le Hussard model, but it was bought second hand and some of the rather important diagrams were left out. Would it be possible to anyone to scan theirs? It would be greatly appreciated.



[Uwek]

I copied this post, which was burried in another topic

Maybe somebody can help?



[Uwek]

Hello everyone, I am also currently working on the Le Hussard model, but it was bought second hand and some of the rather important diagrams were left out. Would it be possible to anyone to scan theirs? It would be greatly appreciated.

Hallo @BoteEnjoyer
we wish you all the BEST and a HAPPY BIRTHDAY



[Omega]

Did you do the second planking & if so do you have any details ie
1 type of glue used
2 did you use contact adhesiove or nails to fix your second planks
3 what order was your second planking
As I am close to the second planking on an old le Hussard Model, any info would be good



[itwbluey]

I have posted these somewhere on here…..let me find a link



[itwbluey]

Post in thread 'Le Hussard 1840, Artesania latina, 1:50'
https://shipsofscale.com/sosforums/threads/le-hussard-1840-artesania-latina-1-50.6109/post-246632
https://shipsofscale.com/sosforums/threads/le-hussard-1840-artesania-latina-1-50.6109/post-246632



[Omega]

Thank you for your advice but your kit is even oder than mine. parts are numbered differently but at least yours are in english. Mine are just spanish & French. Artesania Latina web site does not acknowledge the kit. But I can still work with the instruction (with difficulty)



[Omega]

Probably a bit late for you but I have started the same model (Identical Box). Did you post a Log??
I seem to have all info with the kit (yet to be proved)
