NS Savannah

[ruckus]

I am a former engineer on the NS Savannah and am planning a scratch build. I was able to find templates for the bulkheads and keel. What I am looking for is deck fittings, cranes and other details and measurements to scale down.



[Davidp]

have fun going thru these.
NS Savannah Booklet of General Plans (196X) https://archive.org/details/ma55bogp196x
NS Savannah Capacity Plan (1966) https://archive.org/details/ma55cp1966/page/n1/mode/2up
NS Savannah General Arrangement (2007) https://archive.org/details/ma55haer2007/mode/2up
NS Savannah General Arrangement (2019) https://archive.org/details/ma55ga2019
NS Savannah General Arrangement Details (2022) https://archive.org/details/ma55gad2022
NS Savannah Booklet of General Plans (2023) https://archive.org/details/ma55bogp2023



[Y.T.]

Thanks to enlightening me on what is The NS Savannah.
I checked and found that:
The NS Savannah was the world's first nuclear-powered merchant ship, launched in 1959 as a signature project of President Eisenhower's "Atoms for Peace" initiative. Operating from 1962 to 1972, it served as a combined cargo-passenger liner designed to demonstrate the peaceful, commercial use of nuclear energy. It is now a National Historic Landmark.



[ruckus]

Thanks David for the info. Although I was able to locate most of those drawings there are a few that will definitely be helpful



[Davidp]

you are welcome.
