монитор HMS M15

[Виктор 19]

Здравствуйте, начинающий моделист, заинтересовался монитором HMS M15, не могу найти чертежи, может ли кто в этом помочь?



[Dave Stevens (Lumberyard)]

Здравствуйте, начинающий моделист, заинтересовался монитором HMS M15, не могу найти чертежи, может ли кто в этом помочь?

Hello, aspiring modeler, I am interested in the HMS M15 monitor, I cannot find the blueprints, can anyone help with this?



[Corsair]

Welcome to the SoS forums !



[Peter Schaap]

Welcome to the forum!
Finding official free drawings can be tricky, but there are a few very good commercial options available designed specifically for model builders.
You might want to check the H.M.S. M-15 Plans by Paul Freshney, which include detailed side elevations, hull lines, and superstructure views.
Another great reference is the HMS M15 Card Model Kit by WAK Publishing (1:100 scale), as paper model sheets can often be used as an excellent template for scratch building. [1, 2]
If you are searching online, try using the English terms 'M15-class monitor ship plans' or 'HMS M15 builders drawings'.

I hope someone on the forum has a set in their archive to share with you. Good luck with your start in the hobby!



[Pivot]

Moin,

hallo, ich habe den Papierbaubogen der M15 als PDF erstellt, den kannst Du haben, sende mir über die Mailfunktion bitte deine Mail Adresse damit ich ihn dir schicken kann, hier noch zwei Bider der M15 als RC-Modell eines Modellbau Kollegen,

LG

Gustav



[Pivot]

Moin,

und hier noch ein paar Links mit Infos zu dem Monitor

HMS M15 - Wikipedia

en.wikipedia.org

https://war-book.ru/?s=%D0%9C%D0%BE%D0%BD%D0%B8%D1%82%D0%BE%D1%80%D1%8B+%D1%82%D0%B8%D0%BF%D0%B0+%22M-15%22

LG
Gustav

M15, M18, M19, M20, M21, M22,



[Виктор 19]

Отличная модель! 1sortmani9@gmail.com
